Controller model: Volume type / Down-flow
Suited pressure: 0.1 – 0.6MPa
Suited water temperature: 5-45℃
Water Capacity: 4.5t/h
Tank Diameter Range for Softens: 6”-18” Water
Inlet/Outlet: 1”M (Outer tooth)
Drain: 1/2”M (Outer tooth)
Brine Tank Connection: 3/8”M (Outer tooth)
Rinse Pipe: 1.05”OD (26.7mm)
Base (The connector for tank): 2-1/2” 8NPSM



1. Brief introduction of soft resin control valve

Soft resin control valve TMF63C automatic softener control valve runxin brand with reliable way of opening and closing. It is used as the softener pre-treatment for RO water treatment plant. Its regeneration way is dlow flow type.

2. Features of soft resin control valve

  1. More reliable way of opening and close
  2. Manual function:When it out of electricity or controllers do not work properly, will operate by the hand-wheel.
  3. Keyboard locked function: The key set will lock automatic exceed one minute, you must open the lock over again when you operate, prevent wrong operation.
  4. It adopts LED dynamic colorful screen: The colorful screen flicker express it is in the state of running, otherwise express it is in the state of regeneration.
  5. Prompt power cut secularly: Out of electricity exceed three days, you must reinstall the currently time when the timepiece flicker ceaselessly, the already setting time is not changed.
  6. No coming water while single pot type control valve regeneration
  7. Having output signal connector: via three port of open, close, common down-lead to connect the electromagnetism valve or increase-pressure pumps.
  8. Two modes of flow meter: By changing the process parameter to realize to change the mode to be volume delayed (A-01) or volume timely (A-02).
  9. It could set up maximum interval regeneration days: This parameter means no matter how much flux it is set, or how much flux treated, when it exceeds the maximum interval generation days (could be set within 0 to 40 days), than it will start up regeneration although the flux is not reached the set value.

3.Application of soft resin control valve

  • Household purify, soften system.
  • Boiler softening water system.
  • Ro pre-treatment system.
  • Swimming pool filters equipment.
  • Ion exchange equipment.

4. Specification data



DrainBaseRiser pipeBrine line connectorMax. water treatment capa.(m3/h)Tank diameter Range for softenersTank diameter Range for filters
automatic softTMF63C1”1/2”2-1/2”-8NPSM1.05”3/8”4.56”-18”6”-12”

5. Package information for soft resin control valve

260*235*213mm/pc, 3kg/pc

6. Certification:

ISO9001-2019 safety production licenseCE-certification of RO-water Filtration Drinking Plant

7. Comments from customers:

Comments From Customers

8. Package and transportation:

water Filtration Drinking Plant package and transportation

9. Finished projects:
