Fleck 5600 control valve

Fleck 5600 control valve

Flow Rates: (50 PSI Inlet)
Continuous (15 psi drop): 20 gpm
Peak (25 psi drop):  26 gpm
Max Backwash (25 psi drop):  7 gpm
Valve Material:  Noryl
¾” In/Out Connections
2½” – 8 NPSM Mounting Base
1600 Brine System (softener)
Hard Water Bypass



1. Brief introduction of Fleck 5600 control valve

Fleck 5600 control valve is ideal for residential water softeners 6 – 12” diameter and media filters 8”-10” diameter sizes. The 5600 valve body is offered in the classic mechanical design for rugged construction and simple operation, as well as in the 5600SXT Electronic Programmable style for an extended range of settings and options capabilities.

Fleck Control Valves automatically control the backwash and regeneration cycles for media filters and water softeners to keep your water treatment system working at optimal performance all the time. Fleck control valves are available in time-clock option which can be set to regenerate every day, every two to three days, or on certain days of the week. Fleck valves are also available in metered options for on-demand regeneration based on the volume of water that has been used.

2. Benefits of Fleck 5600 control valve

  1. Non-corrosive, UV-resistant valve body
  2. Economical – small annual power consumption; keeps the time and activates the piston/valve mechanics with a single motor
  3. NSF Standard 44 Certified
  4. UL Registered Components
  5. Mechanical 5600 Valves offer rugged, simple mechanical design which is easy to use
  6. Electronic 5600SXT Valves offer electronic programmable Interface for extended options and configuration settings.
  7. Fully automatic operation

3. Features

  1. Injector/drain modules containing the brine valve, flow controls, and injector are removable from the valve’s exterior
  2. Ruggedly-built timer is designed with heavy-duty 3/8″  wide plastic gears
  3. 5600 controls are user-friendly and easily programmable
  4. Non-corrosive, UV-resistant, fiber-reinforced polymer valve body
  5. Choice of 7 or 12 day clock or demand regeneration with a mechanical meter

4.Options of Fleck 5600 control valve

  1. 7 or 12 Day Timers, Electronic timer, Metered, Pressure Differential, and Other Regeneration Methods
  2. Hot Water
  3. No Hard Water Bypass
  4. Manual Operation
  5. Bypass Valve
  6. Service Valve Operator
  7. Up-Flow Regeneration

5. Specification data for Fleck 5600 control valve

Valve MaterialFiber-reinforced polymer
Inlet/Outlet3/4″. 1″. 1-1/4″
Continuous (15 PSI Drop)20 gpm
Peak (25 PSI Drop)26 gpm
Max.Backwash (25 PSI Drop)7 gpm
Down flow/Up flowboth
Adjustablebrine fill only
Time Available180 minutes
Meter Accuracy Range:0.25 – 15 gpm +/- 5% (1″)
Meter Capacity Range:Standard: 125 – 2,125 gallons
Extended: 1,550 – 26,350 gallons
1-1/2″ Standard: 625 – 10,625 gallons
1-1/2″ Extended: 3,125 – 53,125 gallons
Distributor Pilot13/16″ or 1.05″O.D.
Drain Line1/2″ NPTF
Brine Line3/8″
Injector brine system1600
Mounting Base2-1/2″-8NPSM
Height from top of tank7″
Water Softener6″-12″ diameter
Filters8″-10″ diameter
Electrical Rating24V,110V,220V – 50Hz, 60Hz
PressureHydrostatic: 300 psi
Working: 20 – 125 psi
Temperature34° – 110° F

6. Application:

  • Filters 8” – 10” diameter
  • Whole-House Water Softening
  • Whole-House Water Filtration
  • Point of Entry (POE) Filtration
  • Pre-treatment to RO and other Water Treatment Systems
  • Pre-treatment to Ion Exchange Systems
  • Ice Makers
  • Labs

7. Certification:

ISO9001-2019 safety production licenseCE-certification of RO-water Filtration Drinking Plant
