RO Membrane Elements LG BW 400 R G2

Product name: LG BW 400 R G2 Membrana RO
Modelo: BW 400 R G2
Salt rejection: 99.8%
Effective membrane area: 37m²
Test pressure: 15.5bar
Capacity: 11500GPD
Membrane type: T.F.C
PH range for continue working: 2-11
Brand Name: LG
Condição: Nova
Size: 201*201*1016mm
Weight: 14KG
Material: CARTON
Serviço pós-venda fornecido: suporte técnico de vídeo, instalação em campo, comissionamento e treinamento, serviço de manutenção e reparo em campo, peças de reposição gratuitas, suporte online

Descrição

1. Brief introduction of RO Membrane Elements LG BW 400 R G2

LG Chem’s NanoH2O™ brackish water RO membranes serve various municipal, industrial and commercial applications. Incorporating LG Chem’s proprietary Thin Film Nanocomposite (TFN) technology, all LG BWRO membranes deliver reliable and superior performance with intrinsic anti-fouling properties.
LG BW 400 R G2 membrane elements deliver the highest salt rejection and productivity at lower feed pressures with robust membrane chemistry for long-term stable performance. The RO element also incorporates a unique proprietary feed spacer technology for reducing differential pressure. The results are excellent anti-fouling properties and lower cleaning frequency, chemical use, energy consumption, and total cost of plant ownership. Ideal applications include wastewater reuse and feed water sources with high salinity brackish water.

2. Parameter for RO Membrane Elements LG BW 400 R G2


Modelo	Size (Diameter)		Active area		Permeate flow rate		Stabilized salt rejection	Data sheets
Modelo	milímetros	polegada	pés²	m²	gpd	m³/d	%	Data sheets
LG BW 4040 R	100	4	85	7.9	2500	9.5	99.6
LG BW 400 R Dura	200	8	400	37	10500	39.7	99.7
LG BW 400 R	200	8	400	37	10500	39.7	99.6
LG BW 400 R G2	200	8	400	37	11500	43.5	99.65
LG BW 400 AFR	200	8	400	37	10500	39.7	99.6
LG SW 400 SR	200	8	400	37	6000	22.7	99.85
LG SW 400 R	200	8	400	37	9000	34.1	99.85
LG SW 400 GR	200	8	400	37	7500	28.4	99.85
